When do I get the trouble light from a DSc panel?
When do I get the trouble light from a DSc panel?
I get the trouble light. Click to expand… When the trouble clears, the light will go out. What’s the problem? I have been using a DSC 832 panel in my house for a number of years now.
What are the problems with the DSC alarm system?
DSC Alarm System Troubles 1 Light 1 = Low Panel Battery 2 Light 2 = Bell/Horn Trouble 3 Light 3 = General System Trouble 4 Light 4 = General System Tamper 5 Light 5 = General System Supervisory 6 Light 6 = Not Used 7 Light 7 = 5204 Power Supply Module Low Battery 8 Light 8 = 5204 Power Supply Module AC Fail
How long does it take to reset a DSc alarm?
Hold it down for at least 2 seconds to disengage the alarm. You will notice the lights on the alarm change from red to green to signal that the alarm has been reset. This also helps to reset the low battery light once the power has been restored.
How can I Stop my DSC home alarm from beeping?
You can easily toggle this on or off by pressing and holding the “Chime” button on any keypad that has function keys. For keypads without a chime button, just press “*4”. On this page, I’ll show you how to silence trouble beeping, and how to use a few easy keypad commands to find the source of the trouble.
How can I tell if my DSC power series is in trouble?
Press the number corresponding to the trouble condition to view the additional information. To view a trouble condition, press [*] [2]. The trouble light will flash and the LCD will display the first trouble condition present. Use the arrow keys to scroll through all trouble conditions present.
How long does it take DSC power panel to charge?
The main panel battery is below 11.5 VDC. The trouble condition will not clear until the battery is at least 12.5VDC under load. If the battery is new, allow 1 hour for the battery to charge. Ensure the panel is getting proper AC power.
DSC Alarm System Troubles 1 Light 1 = Low Panel Battery 2 Light 2 = Bell/Horn Trouble 3 Light 3 = General System Trouble 4 Light 4 = General System Tamper 5 Light 5 = General System Supervisory 6 Light 6 = Not Used 7 Light 7 = 5204 Power Supply Module Low Battery 8 Light 8 = 5204 Power Supply Module AC Fail
How to troubleshoot DSC power series bulwark battery?
The PC5204 battery is below 11.5 VDC. The trouble condition will not clear until the battery is at least 12.5VDC under load. If the battery is new, allow 1 hour for the battery to charge. Ensure the module is getting proper AC power. Measure across the two AC terminals of the module and ensure the AC input is between 16 and 18VAC.
