Is the Aiphone JF series compatible with other phones?
Is the Aiphone JF series compatible with other phones?
The JF Series stations are not compatible with other intercom stations from Aiphone. All compatible door and sub master stations must contain the prefix of “JF”, ex. JF-DV. What type of wire is used with the JF series?
How many images can I record on my jf-2med Aiphone?
Record max. 50 calls (8 images per call) with up to 10 calls protected from overwriting N/O dry contact, 24V AC/DC 500mA (use RY-18L for larger contact rating or RY-3DL for 2 doors) Need Help? Talk in real time with a member of our Technical Support departments.
What kind of wire do I need for Aiphone JF?
The recommended wire for the JF Series is Aiphone’s solid, non-shielded two and four-conductor wires, part numbers 871802 and 871804 respectively. Click here to view the JF Series installation manual. From the door station to the master station, the maximum wiring distance is 330′ (100m).
Can you use the JF series on Aiphone?
The JF Series stations are not compatible with other intercom stations from Aiphone. All compatible door and sub master stations must contain the prefix of “JF”, ex. JF-DV.
Why is my jf-2med not connecting to the master station?
This can be caused by environmental factors, exceeding recommended wiring distance or wire type, ambient electrical interference, or physical damage to the unit. Bring the door station to the JF-2MED and connect the A1/A2 terminals on the door station to the A1/A2 connections on the master station.
How do I Turn Off the jf-2med lights?
Turn off the JF-2MED using the power switch on the left-hand side. Disconnect all connections from the JF-2MED except for the power wires. Power the unit back on and check for flashing lights. Begin reconnection stations until the lights begin to flash again, this should tell you where the short lies.
Record max. 50 calls (8 images per call) with up to 10 calls protected from overwriting N/O dry contact, 24V AC/DC 500mA (use RY-18L for larger contact rating or RY-3DL for 2 doors) Need Help? Talk in real time with a member of our Technical Support departments.
