How many wireless zones does Vista-21iP have?

64 zones
A VISTA-21iP has 64 zones. However, the system will require some add-ons to support this many zones. By default, the system only has 8 hardwired zone terminals.

What is Zone doubling?

Zone doubling is the practice of installing two resistors on a single zone and programming the panel to operate in zone doubling mode for that zone. When the resistors are in parallel the total resistance is 2K. The 3K resistors are used on the lower zones and the 6.2K is used on the upper zones.

How do I default a Vista 20p panel?

1. Access the alarm’s programming mode by entering the installer code, followed by “8,” “0” and “0,” into the control panel.
2. Press the “*” button on the control panel, followed by the “9” and “7” buttons to reset the security system to factory settings.

What happens when zone doubling on a Honeywell VistA system?

Only Normally Closed devices can be doubled. A short across either resistor of a doubled zone will cause a tamper response (Day/Night) on both doubled zones. When the system is armed, this will report as an E135 and is treated as an alarm. When disarmed, it reports as an E383 and displays as a trouble. Double similar zone types together.

How do I program a wired zone on a vista panel?

This is why zone 1 cannot be used for zone-doubling. To program zones 2 and higher on a Vista P-Series panel, do the following: Enter Programming. On an Alpha keypad, such as the 6160, or 6160RF, enter Installer Code (default is 4112) + [8] + [00]. You should see “Installer Code 20” on the display.

What do the Honeywell Vista 20p and 21ip do?

The Honeywell VISTA 15P, 20P and 21iP are hardwired security systems that can each serve as the central hub for a user’s security setup. Since these systems do not come with their own display screen, a user may feel somewhat intimidated when working with one of these panels.

What are the dip and address settings for Vista?

The address and dip switch settings depend on which panel as well as which zone numbers are being used. We will be discussing the Vista-15P, Vista-20P, and Vista-21iP panels.

What does the Vista 21ip control panel do?

The VISTA-21iP gives you the ability to send alarm signals and upload/download via an Internet Protocol (IP), improving the speed at which information can be delivered to and from the control panel.

Only Normally Closed devices can be doubled. A short across either resistor of a doubled zone will cause a tamper response (Day/Night) on both doubled zones. When the system is armed, this will report as an E135 and is treated as an alarm. When disarmed, it reports as an E383 and displays as a trouble. Double similar zone types together.

What is maximum zone capacity of Vista 21ip?

With a maximum zone capacity of 48, the VISTA-21iP delivers a full communications solution with an integrated Internet communicator and optional snap-in LTE radio— right on board. It delivers the same installation advantages, innovative end-user benefits and robust system capacity you’ve come to expect from all VISTA panels – plus a whole lot more.

What are the features of Honeywell home Vista 21ip?

Honeywell Home high capacity, feature-rich VISTA-21iP lets you deliver more value to your customers on each and every sale. The VISTA-21iP provides up to 48 zones of protection, an on-board IP connection, graphic keypad support and dual partitions.
