How many wireless zones can a VISTA-20P have?

48 zones
The high capacity, feature-rich VISTA-20P lets you deliver more value to your customers on each and every sale with up to 48 zones of protection, Internet uploading/downloading, graphic keypad support and dual partitions.

How do I program a vista panel?

During the reboot cycle (within 50 seconds of power up) press and hold the * (star) and # (pound) keys simultaneously for 3 full seconds. If you successfully get into programming you will see “installer code 20” displayed if you have an alphanumeric keypad or “20” if you have a Fixed English keypad.

Is the Ademco Vista 20p a good alarm system?

The Ademco Vista 20P has very good built-in lightning protection, even without an earth ground connection. See why a Vista 20P Ademco Alarm System is such a good choice for the average-size home. More information on Honeywell Security Systems.

Where is the red jumper on the Ademco Vista 20p?

The Ademco Vista 20P has the ability to supervise the bell connection, so you’ll get a trouble beeping at the keypad if the siren wire is cut. To enable this feature, cut the red jumper on the circuit board; it’s located just above the terminal strip on the left end.

How to program a wireless zone on my Honeywell vista-20p?

Complete the following steps to program a wireless zone on a Honeywell VISTA-20P: 1. Access system programming. Enter the installer code (the default code is 4112) + 800 on a keypad. The will display “Installer 20”, showing that you have successfully entered system programming.

What are the unlabeled keypad keys for Ademco Vista?

Unlabeled keypad keys (known as ABCD keys) for special functions Zone Programming (Expert Mode) Press 58. Same options as *56 mode, but with fewer prompts. Intended for those familiar with this type of programming, otherwise *56 mode is recommended. Output Device Mapping Press 79.

How to enter program mode on Ademco Vista?

A TO ENTER PROGRAMMING MODE (using an alpha keypad connected to the control): A.POWER UP, then press [✱] and [#] at the same time, within 50 seconds of powering up (this method must be used if ✱98 was used to exit program mode). OR B. Initially, key: Installer Code (4 + 1 + 1 + 2) plus 8 + 0 + 0. PROGRAMMING MODE COMMANDS

What are the keypad keys for Ademco Vista?

Function Key Programming Press ∗57. Unlabeled keypad keys (known as ABCD keys) for special functions Zone Programming (Expert Mode) Press ∗58. Same options as *56 mode, but with fewer prompts. Intended for those familiar with this type of programming, otherwise *56 mode is recommended. Output Device Mapping Press ∗79.

How to enter field number in Ademco Vista?

Task Command/Explanation Go to a Data Field Press [∗] + [Field Number], followed by the required entry. Entering DataWhen the desired field number appears, simply make the required entry. When the last entry for a field is entered, the keypad beeps three times and automatically displays the next data field in sequence.

Complete the following steps to program a wireless zone on a Honeywell VISTA-20P: 1. Access system programming. Enter the installer code (the default code is 4112) + 800 on a keypad. The will display “Installer 20”, showing that you have successfully entered system programming.
