How do you program a Concord 4?
How do you program a Concord 4?
To enter program mode: Press 8, 4321, 0, 0. The display shows SYSTEM PROGRAMMING.
What kind of security system does GE Concord 4 have?
The Concord 4 is a hybrid system, able to use both hardwired and wireless devices. It can handle 2-wire smoke detectors for fire protection, and has 2 programmable outputs for controlling auxiliary devices such as lights or relays.
What is the user manual for Concord 4?
The Concord 4 User Manual (P/N 466-2183) contains user worksheets that you should fill out during the installation and programming of the system. For multiple-partition systems, we suggest a user manual for each partition. Read these instructions and all related documentation entirely before installing or operating this product.
Where are the dealer and installer codes stored on a Concord 4?
The Master, Installer and Dealer 4-digit codes for the Concord 4 are stored as pairs of 2-digit hexadecimal integers at known consecutive addresses within a 24C256L EEPROM chip. This memory chip sits in a socket located on the alarm panel circuit board where shown (1rst image below).
Can you reset the passcode on Concord 4?
You’ll gain full access to system programming, including stored phone numbers, and you can of course reset all the passcodes as desired (see the Concord 4 Installation Manual for details). Now you’re in control! Concord 4 EEPROM Location.jpg (263.42 kB, 1005×749 – viewed 1080 times.)
The Concord 4 User Manual (P/N 466-2183) contains user worksheets that you should fill out during the installation and programming of the system. For multiple-partition systems, we suggest a user manual for each partition. Read these instructions and all related documentation entirely before installing or operating this product.
What are the numbers on the Concord 4 series security system?
Concord 4 Series Security Systems Part Numbers: 600-1021-95R 600-1022-95R 600-1040 Notices FCC Part 15 Information to the User Changes or modifications not expressly approved by GE Security can void the user’s authority to operate the equipment.
What kind of RF does Concord 4 use?
Built-in RF receiver Allows use of up to 96 or 32 319.5 MHz crystal and/or SAW learn mode wireless sensors and touchpads. 2 Concord 4 Installation Guide Phone line connection Allows panel to communicate with central monitoring station and/or pagers. length to Note: The total current sourced from all terminals cannot exceed 1 amp. Panel location
What are the sensor characteristics of the Concord 4?
Sensor group characteristics 130 Sensor text 134 System event triggers 136 Sensor group event triggers 137 Sensor number event triggers 138 System feature event triggers 141 Response characteristics 143 Response numbers 143 Specifications 145 Concord 4 Installation Manual iii Important information Intended use
