How do I program on Vista 128?

Users must enter the programming mode to change the installer code on the Honeywell Vista 128BPT control panel. From the Vista keypad, enter into the programming mode by entering the existing 4 digit Installer Code + [8] + [0] + [0] + [0].

How many zones does Vista 128 have?

Provides nine style-B hardwired zones. Supports up to 119 additional zones using a built-in polling (V-Plex®, multiplex) loop interface. Supports up to 127 wireless zones using up to two 5800 series wireless receivers (fewer if using hardwire and/or polling loop zones)

How do I make Vista 128bpt default?

Complete the following steps to factory default your Honeywell VISTA P-Series System:

1. Enter programming. Go to your VISTA Keypad.
2. Perform the default. Enter the command [*97].
3. Default the account. Enter the command [*96].
4. Confirm the default. Press [*99] to exit programming.

How many expansion zones does Ademco Vista 128bp support?

• Provides tamper supervision on the hardwire zones. • Supports up to 50 2-wire latching glassbreak detectors on zone 8. • Supports up to 241 additional expansion zones (119 for the VISTA-128BP) using a built-in polling (multiplex) loop.

Is the vista-128fbpt compliant with ul864?

UL864 (Commercial Fire) Compliance General Requirements The VISTA-128FBPT/VISTA250FBPT control panels provide features that allow the system to meet UL864 Commercial Fire requirements. To meet these requirements, follow the guidelines outlined in this section.

What’s the difference between the Vista 250bp and the 128bp?

NOTE: All references in this manual for number of zones, number of user codes, number of access cards, and the event log capacity, use the VISTA-250BP’s features. The following table lists the differences between the VISTA-128BP and the VISTA-250BP control panels.

How many zones are there in Vista 250bp?

Feature VISTA-128BP VISTA-250BP Number of Zones 128 250 Number of User Codes 150 250 Number of Access Cards 250 500 Event Log Capacity 512 1000 VistaKey Modules 8 15 VISTA-128BP/VISTA-250BP Installation and Setup Guide
