How can I tell if my DSC power series is in trouble?

Press the number corresponding to the trouble condition to view the additional information. To view a trouble condition, press [*] [2]. The trouble light will flash and the LCD will display the first trouble condition present. Use the arrow keys to scroll through all trouble conditions present.

What are the trouble codes for DSC alarms?

Understanding DSC Alarm Trouble Codes. 1 Service Required (press [1] for more information) 1.1 Low Battery (main battery in panel) 1.2 Bell Circuit. 1.3 System Trouble. 1.4 System Tamper. 1.5 Module Supervision. 1.6 RF Jam Detected. 1.7 PC5204 Low Battery. 1.8 PC5204 AC Failure.

Is there a problem with the powerseries control panel?

possible trouble conditions that can occur on any PowerSeries control panel (Power432, Power632, Power832 and Power864). LED Keypad, LCD Fixed-Message Keypad To view a trouble condition, press [*][2]. The trouble light will flash. Refer to the chart below to determine the trouble condition(s) present.

How long does it take DSC power panel to charge?

The main panel battery is below 11.5 VDC. The trouble condition will not clear until the battery is at least 12.5VDC under load. If the battery is new, allow 1 hour for the battery to charge. Ensure the panel is getting proper AC power.

What does a zone light on a DSc panel mean?

* 2. A zone light will indicate the specific trouble. If the trouble has cleared, pressing pound will usually clear everything. (You must log in or sign up to reply here.) Want to reply to this thread or ask your own question? You’ll need to choose a username for the site, which only take a couple of moments ( here ).

What should the voltage be on a DSc battery?

To verify the battery charging circuit disconnect the battery and measure the voltage across the two battery leads. The voltage should be 13.75VDC. With the battery connected remove AC from the panel and measure across the battery terminals. If the voltage is below 12.5VDC replace the battery.

How to troubleshoot a DSc power series Siren?

Remove the wires from Bell+ and Bell- and measure the resistance of the wires. If an open circuit is measured there is a break in the wiring or the siren is defective. Put a 1K resistor (brown, black, red) across Bell+ and Bell- to verify the trouble condition clears.

How to enable or disable door chime on DSC power series?

Here are step-by-step instructions on how enable or disable the door chime on a DSC Power Series security alarm monitoring panel: Click Here to Download a User Manual for Your System! Press and Hold the Chime button for two seconds . When complete the Keypad will Beep. Press * and then 4 .

What does number 1 mean on a DSc alarm?

Number 1 corresponds to Service Required, though you may just do it yourself depending on the specific trouble. To know the specific trouble, press number 1. If it displays “Low Battery” and you had a recent power outage, wait 24 hours after the power comes back on. The battery just needs to recharge first.

What does low battery mean on DSC alarm?

1. Low Battery Number 1 corresponds to Service Required, though you may just do it yourself depending on the specific trouble. To know the specific trouble, press number 1. If it displays “Low Battery” and you had a recent power outage, wait 24 hours after the power comes back on. The battery just needs to recharge first.

What should I do if I hear a dial tone on my DSC?

If there is a dial tone, check first if there are visible disconnections between your panel and the phone box. After that, you may need to contact your security company to check further for damaged connections. You also need to contact them if you recently had a cable telephone or DSL installation so they can update your system.
