How can I see my CCTV on the same network?

How to view your IP camera remotely via a web browser

1. Find your camera’s IP address.
2. Open a web browser and type the IP address.
3. Go to SETTING > BASIC > Network > Information to find the HTTP port number used by the camera.
4. After you change the port, you will need to reboot the camera in order to save the changes.

How can I access my DVR anywhere?

Please follow these setup instructions to setup remote Internet access for the dual codec JPEG DVR:

1. Assign your DVR an IP Address.
2. Connect to your DVR on your LAN – Local Area Network.
3. Setting up Port Forwarding on your Router.
4. Setting up a Static DHCP IP address for your DVR.
5. Remote Internet Setup.

How do I know what port my DVR is using?

Step 2: Finding your DVR’s IP address and Ports When you start your DVR, the camera feeds should be on the main screen. Right click with your mouse and choose the last selection Main Menu to bring up the main menu. Look under the SETTING section and choose the option NETWORK.

What should I replace my Q-see DVR with?

The main equipment any previous Q-See customer should replace is the DVR or NVR. Q-See, while going out of business, has discontinued all of their apps and PC software.

How to port forwarding of multiple DVRs on single network?

On the 1st DVR you will record the assigned IP Address and make note of the HTTP port (should be 80) On the 2nd DVR you will Navigate to the same network configuration and record the IP address and change the HTTP port to 81

What should the HTTP port value be on a DVR?

Be sure to change the HTTP port value from 80 to 8080 in the DVR’s networking section. As long as you configure everything correctly in both the DVR and your router, everything should work fine. The first thing you should do when configuring port forwarding is determine all of your network information.

Can a Poe camera connect to a DVR system?

IP cameras or PoE cameras use Ethernet networking cable to connect to NVR systems. HD Coaxial cameras use coax cable to connect to DVR systems. Below we outline what information our team will need to suggest the best cameras for your system. Compatibility is always a question when it comes to PoE security cameras.

What are the rules for port forwarding on a DVR?

For our video recorders, at a minimum you must enable port forwarding rules for ports 80 and 37777 for remote viewing to work smoothly. You must make 2 individual rules in your router’s firewall settings. One port rule for port 80, and one rule for port 37777.

Be sure to change the HTTP port value from 80 to 8080 in the DVR’s networking section. As long as you configure everything correctly in both the DVR and your router, everything should work fine. The first thing you should do when configuring port forwarding is determine all of your network information.

How can I have two DVRs on the same network?

The best way to do this is to leaving one of the DVRs with the default TCP and UDP ports (37777 TCP & 37778 UDP). Then Change the HTTP to 88 if you haven’t done so. The Next DVR you can do (47777 TCP & 47778 UDP).

What do ports do surveillance video recorders use?

Depending on the manufacturer of your surveillance video recorder, it will use specific ports for web login, data communication, and video streaming to serve up the camera feed. For recorders purchased from CCTV Camera World it is simple. All of our recorders have the following default ports configured when they ship:
